Tie Rod End

MERCEDES-BENZ / AMG GT (C190) | AMG GT / GT S / Tie Rod End / FRONT AXLE LH (C= M14X1.5) / CTE21005L

Technical Specification Matrix

CTE21005L 是 MERCEDES-BENZ 專用的轉向拉桿接頭 (FRONT AXLE LH (C= M14X1.5))。本產品為 OEM 規格替代零件，適配原廠料號 204 330 09 03,A204 330 09 03。

PARAMETER	METRIC / VALUE
Designation	Tie Rod End
Position	FRONT AXLE LH (C= M14X1.5)
OE 替代料號 (Original Equipment Numbers)	204 330 09 03 A204 330 09 03
Length	195 mm
Width	56 mm
Height	85 mm
Net Weight	0.7 kg

輸入廠牌、車款、車型年份或 17 位 VIN 碼，系統將自動比對原廠規格，為您精確鎖定愛車專用的適配零件。

CTE No.	POSITION	OE No.
CBH21017	FRONT UPPER ARM INNER	203 333 10 14
CBH21025	FRONT UPPER ARM INNER	204 333 0414 A2043330414
CS-2112L	FRONT UPPER LH	203 330 01 11 203 330 16 11 203 330 35 11 203 330 39 11 204 330 33 11 204 330 43 11 204 330 87 11 A 203 330 01 11 A 203 330 16 11 A 203 330 35 11 A 203 330 39 11 A 204 330 43 11 A 204 330 87 11
CS-2112R	FRONT UPPER RH	203 330 02 11 203 330 17 11 203 330 36 11 203 330 40 11 204 330 34 11 204 330 44 11 204 330 88 11 A 203 330 02 11 A 203 330 17 11 A 203 330 36 11 A 203 330 40 11 A 204 330 44 11 A 204 330 88 11
CS-2121L	FRONT LOWER LH	204 330 31 11 204 330 67 11 A204 330 31 11 A204 330 67 11
CS-2121R	FRONT LOWER RH	204 330 32 11 204 330 68 11 A204 330 32 11 A204 330 68 11
CTE21005L	FRONT AXLE LH (C= M14X1.5)	204 330 09 03 A204 330 09 03
CTE21005R	FRONT AXLE RH (C= M14X1.5)	204 330 10 03 A204 330 10 03

Model (Year)
AMG GT (C190) \| AMG GT / GT S AMG GT Roadster (R190) C-CLASS (W204) C-CLASS Coupe (C204) C-CLASS T-Model (S204) E-CLASS Convertible (A207) E-CLASS Coupe (C207) SLC (R172) SLK (R172) SLS AMG (C197) SLS AMG Roadster (R197)
