Tie Rod End

TOYOTA / HARRIER (_U6_) / Tie Rod End / FRONT AXLE RH (C= M16X1.5) / CTE02004R

Name: CTE02004R
Brand: CTE
SKU: CTE02004R
Price: 782.00 TWD
Availability: InStock

Tie Rod End/LEXUS/TOYOTA/HARRIER (_U6_)/HS (ANF10)/MIRAI (JPD1_)/NX (_Z1_)/RAV 4 III (_A3_) | RAV 4 / VANGUARD/RAV 4 IV (_A4_)

Technical Specification Matrix

CTE02004R 是 TOYOTA 專用的轉向拉桿接頭 (FRONT AXLE RH (C= M16X1.5))。本產品為 OEM 規格替代零件，適配原廠料號 45046-09650,45046-49195。

更多相關商品

PARAMETER	METRIC / VALUE
Designation	Tie Rod End
Position	FRONT AXLE RH (C= M16X1.5)
OE 替代料號 (Original Equipment Numbers)	45046-09650 45046-49195
Length	215 mm
Width	59 mm
Height	75 mm
Net Weight	0.9 kg

Find More Auto Parts

快速找到適配您需要的專業零件

輸入廠牌、車款、車型年份或 17 位 VIN 碼，系統將自動比對原廠規格，為您精確鎖定愛車專用的適配零件。

Compatible Models

CTE No.	POSITION	OE No.
CBH02041	FRONT LOWER ARM REAR	48068-42051 48068-45050 48069-42050 48069-42051
CBH02044	FRONT LOWER ARM INNER	48068-02130 48068-12300 48068-47050 48068-F4010 48069-02130 48069-12300 48069-47050 48069-F4010 48654-02040 48654-05060 48654-42030 48654-42040 48654-47030 48655-42050
CBH02060	REAR UPPER AXLE	48725-78010 48760-0R010 48760-0R020 48760-0R030 48760-42010 48760-42020 48760-42030 48760-42040 48760-42060 48760-48110 48760-78010 48780-0R010 48780-0R020 48780-0R030 48780-42010 48780-42020 48780-42030 48780-42040 48780-42060 48780-48110 48780-78010
CBJ02016A	FRONT LOWER LH/RH	43330-02111 43330-05040 43330-09630 43330-09631 43330-09720 43330-09770 43330-09A30 43330-09A40 43330-19245 43330-19255 43330-19275 43330-49095 43330-49195 43330-49215
COS02004	FRONT
CRE02080	FRONT AXLE LH/RH	44250-42150 45503-30160 45503-42030 45503-53010 45510-0R010 45510-0R040 45510-0R041 45510-0R050 45510-0R051 45510-0R070 45510-0R100 45510-42030 45510-42080 45510-42100 45510-42120 45510-42130 45510-42160 45510-42161 45510-42170 45510-42171 45510-42230 455
CRE02158	FRONT AXLE LH/ RH	45500-05020 45500-05030 45503-0F010
CS-252L	FRONT LOWER LH	10140-25100 40170-05500 48069-02180 48069-0R010 48069-0R020 48069-0R030 48069-42050 48069-42051 48069-42060
CS-252R	FRONT LOWER RH	10140-25101 40170-05400 48068-02180 48068-0R010 48068-0R020 48068-0R030 48068-42050 48068-42051 48068-42060
CS-255L	FRONT LOWER LH	10140-25100 40170-05500 48069-02180 48069-0R010 48069-0R020 48069-0R030 48069-42050 48069-42051 48069-42060 CS-252L+CBJ02016A
CS-255R	FRONT LOWER RH	10140-25101 40170-05400 48068-02180 48068-0R010 48068-0R020 48068-0R030 48068-42050 48068-42051 48068-42060 CS-252R+CBJ02016A
CS-298L	REAR UPPER LH	48780-42010 48780-42030 48780-48110 48780-78010
CS-298R	REAR UPPER RH	48760-42010 48760-42030 48760-48110 48760-78010
CS02163L	REAR AXLE LH	48790-0R010 48790-42020 48790-42040
CS02163R	REAR AXLE RH	48770-0R010 48770-42040
CS02164L	REAR AXLE LH	48740-42010 48740-42020
CS02164R	REAR AXLE RH	48730-42040 48730-42050
CSL02066D1	FRONT (A= 360MM)	48820-02070 48820-02080 48820-0R010 48820-42030 48820-47020 48820-47030
CSL02081	REAR AXLE LH/RH	48830-0R010 48830-42021 48830-42022
CTE02004L	FRONT AXLE LH (C= M16X1.5)	45047-09310 45047-49135
CTE02004R	FRONT AXLE RH (C= M16X1.5)	45046-09650 45046-49195
