Stabilizer Link
Technical Specification Matrix
CSL03037 是 MAZDA 專用的 平衡桿拉桿 (REAR (A= 76mm))。
本產品為 OEM 規格替代零件，適配原廠料號 1223923,1231452,1253969,1304120,1310333,1335548,1469208,1734686,2408359,3M51 5C486 BE,3M515C486BC,3M515C486BD,3M515C486BF,3M5J-5C486-BF,BP4K-28-170A,BP4K-28-170C,BP4K-28-170D,BP4K-28-170E,BP4K-28-170F,BP4K-28-170G,BP4K-28-170H。
| PARAMETER | METRIC / VALUE |
|---|---|
| Designation | Stabilizer Link |
| Position | REAR (A= 76mm) |
| OE 替代料號 (Original Equipment Numbers) |
|
| Length | 117 mm |
| Width | 39 mm |
| Height | 75 mm |
| Net Weight | 0.4 kg |
Find More Auto Parts
快速找到適配您需要的專業零件
輸入廠牌、車款、車型年份或 17 位 VIN 碼，系統將自動比對原廠規格，為您精確鎖定愛車專用的適配零件。
Compatible Models
| CTE No. | DESIGNATION | POSITION | OE No. | |
|---|---|---|---|---|
 |
CBH03020 | REAR LINK INNER/ OUTER |
|
|
 |
CBH03048 | REAR LINK |
|
|
 |
CS-341 | REAR AXLE LH/ RH |
|
|
 |
CS-347 | REAR UPPER LH/ RH |
|
|
 |
CS-369L | FRONT LOWER LH |
|
|
 |
CS-369R | FRONT LOWER RH |
|
|
 |
CSL03037 | REAR (A= 76MM) |
|
| Model (Year) |
|---|
|
2 Saloon (DE_) 3 (BK) | AXELA 3 (BL) | AXELA 3 Saloon (BK) | AXELA 3 Saloon (BL) 3 Saloon (BL) | AXELA 3 Saloon (BM_, BN_) | AXELA 5 (CR) | PREMACY 5 (CW) | PREMACY |
| Model (Year) |
|---|
|
C-MAX (DM2) FOCUS C-MAX (DM2) FOCUS II (DA_, HCP, DP) FOCUS II Convertible FOCUS II Estate Van FOCUS II Saloon (DB_, FCH, DH) FOCUS II Turnier (DA_, FFS, DS) |
