Stabilizer Link

TOYOTA / CALDINA Estate (_T19_) / Stabilizer Link / REAR (A= 250mm) / CSL02003

Technical Specification Matrix

CSL02003 是 TOYOTA 專用的平衡桿拉桿 (REAR (A= 250mm))。本產品為 OEM 規格替代零件，適配原廠料號 48830-32040。

PARAMETER	METRIC / VALUE
Designation	Stabilizer Link
Position	REAR (A= 250mm)
OE 替代料號 (Original Equipment Numbers)	48830-32040
Length	283 mm
Width	33 mm
Height	49 mm
Net Weight	0.3 kg

輸入廠牌、車款、車型年份或 17 位 VIN 碼，系統將自動比對原廠規格，為您精確鎖定愛車專用的適配零件。

CTE No.	POSITION	OE No.
CBJ02012A	FRONT LOWER LH/RH	43330-02020 43330-02040 43330-05020 43330-09030 43330-09040 43330-09060 43330-09130 43330-19095 43330-26265 43330-29045 43330-29046 43330-29047 43330-29055 43330-29056 43330-29065 43330-29265 43330-29315 43330-29325 43330-29375 43340-29025 43340-29026 433
CRE02087	FRONT AXLE LH/ RH	45503-29445 45503-29625
CSL02003	REAR (A= 250MM)	48830-32040
CSL02036L	FRONT LH (A= 70MM)	48810-05010 48810-05011 48810-05012 48810-20020 48810-44010
CSL02036R	FRONT RH (A= 70MM)	48820-05011 48820-05012 48820-20040 48820-44010

Model (Year)
CALDINA Estate (_T19_) CARINA VII Saloon (_T21_) CORONA Saloon (_T19_) HARRIER (_U1_) HIGHLANDER / KLUGER (_U2_)

Model (Year)
RX (MCU15)
