Control Arm
Technical Specification Matrix
CS-328R 是 MAZDA 專用的 控制臂 (FRONT LOWER RH)。
本產品為 OEM 規格替代零件，適配原廠料號 1003575,1009580,1015260,1021219,1045655,1052505,1056835,1063236,1071694,1330238,1710792,1E01-34-300,1E01-34-300A,1E01-34-300B,1E01-34-300C,1E01-34-300D,1E01-34-300E,1E01-34-300F,4S613042CA,96FB3042BF,96FB3042BG,98FB3042CC,98FB-3042-CD,ME96FB3042CA。
| PARAMETER | METRIC / VALUE |
|---|---|
| Designation | Control Arm |
| Position | FRONT LOWER RH |
| OE 替代料號 (Original Equipment Numbers) |
|
| Length | 390 mm |
| Width | 397 mm |
| Height | 79 mm |
| Net Weight | 3.3 kg |
Find More Auto Parts
快速找到適配您需要的專業零件
輸入廠牌、車款、車型年份或 17 位 VIN 碼，系統將自動比對原廠規格，為您精確鎖定愛車專用的適配零件。
Compatible Models
| CTE No. | DESIGNATION | POSITION | OE No. | |
|---|---|---|---|---|
 |
CBH03030 | FRONT LOWER ARM REAR |
|
|
 |
CBH03031 | FRONT LOWER ARM INNER |
|
|
 |
CBH03066 | REAR ARM INNER |
|
|
 |
CBJ03004A | FRONT LOWER LH/ RH |
|
|
 |
CBJ03005A | FRONT LOWER LH/ RH |
|
|
 |
CRE03049 | D= M14X2.0 , C= M14X1.5 |
|
|
 |
CS-327L | FRONT LOWER LH |
|
|
 |
CS-327R | FRONT LOWER RH |
|
|
 |
CS-328L | FRONT LOWER LH |
|
|
 |
CS-328R | FRONT LOWER RH |
|
|
 |
CSL11001 | FRONT (A= 238MM) |
|
| Model (Year) |
|---|
|
121 III (JASM, JBSM) 121 III Hatchback Van (JASM, JBSM) |
| Model (Year) |
|---|
|
COURIER Pickup FIESTA Box Body/MPV (J5_, J3_) | COURIER FIESTA Hatchback Van (JV_) | COURIER FIESTA IV (JA_, JB_) PUMA (EC_) |
