Control Arm

VOLKSWAGEN / CALIFORNIA T5 Camper (7EC, 7EF, 7EG, 7HF, 7HC) / Control Arm / FRONT LOWER LH / CS-2031L

Technical Specification Matrix

CS-2031L 是 VOLKSWAGEN 專用的控制臂 (FRONT LOWER LH)。本產品為 OEM 規格替代零件，適配原廠料號 7H0 407 151E,7H0 407 151F,7H0 407 151G。

PARAMETER	METRIC / VALUE
Designation	Control Arm
Position	FRONT LOWER LH
OE 替代料號 (Original Equipment Numbers)	7H0 407 151E 7H0 407 151F 7H0 407 151G
Length	540 mm
Width	370 mm
Height	125 mm
Net Weight	8.5 kg

輸入廠牌、車款、車型年份或 17 位 VIN 碼，系統將自動比對原廠規格，為您精確鎖定愛車專用的適配零件。

CTE No.	POSITION	OE No.
CBH20027	FRONT LOWER ARM INNER	2H0 407 183A 7H0 407 183
CBH20032	FRONT LOWER ARM REAR	7H0 407 182 7H0 407 182A
CBJ20009	FRONT LOWER LH/ RH	7576024 7E0 407 361 7E0 407 361A 7H0 407 361 7H0 407 361A 7H8 407 361 7H8 407 361A 7H8 407 362
CBJ20009A	FRONT LOWER LH/ RH	7576024 7E0 407 361 7E0 407 361A 7H0 407 361 7H0 407 361A 7H8 407 361 7H8 407 361A 7H8 407 362
CRE20010	D= M16X1.5 , C= M16X1.5	7H0 422 807
CS-2031L	FRONT LOWER LH	7H0 407 151E 7H0 407 151F 7H0 407 151G
CS-2031R	FRONT LOWER RH	7H0 407 152E 7H0 407 152F 7H0 407 152G
CSL20015	FRONT (A= 260MM)	7H0 411 317 7H0 411 317A 7H5 411 317 7H5 411 317A 7H5 411 317B 7H5 411 317D 7H5 411 317E
CSR20001L	FRONT AXLE LH	7E0 419 803 7H0 419 803B 7H0 419 803C 7H0 419 803D 7H0 419 803E 7H0 419 803F
CSR20001R	FRONT AXLE RH	7E0 419 804 7H0 419 804B 7H0 419 804C 7H0 419 804D 7H0 419 804E 7H0 419 804F
CTE20004L	FRONT AXLE LH (C= M16X1.5)	7E0 422 817 7H0 422 817A 7H0 422 817B 7H0 422 817C 7H0 422 817D
CTE20004R	FRONT AXLE RH (C= M16X1.5)	7E0 422 818 7H0 422 818A 7H0 422 818B 7H0 422 818C 7H0 422 818D

Model (Year)
CALIFORNIA T5 Camper (7EC, 7EF, 7EG, 7HF, 7HC) MULTIVAN T5 (7HM, 7HN, 7HF, 7EF, 7EM, 7EN) TRANSPORTER T5 Bus (7HB, 7HJ, 7EB, 7EJ) \| TRANSPORTER / CARAVELLE \| EUROVAN \| CARAVELLE TRANSPORTER T5 Platform/Chassis (7JD, 7JE, 7JL, 7JY, 7JZ, 7F TRANSPORTER T5 Van (7HA, 7HH, 7EA, 7EH)
