Ball Joint

CITROËN / C3 I (FC_, FN_) / Ball Joint / FRONT LOWER LH/ RH / CBJ25001A

Technical Specification Matrix

CBJ25001A 是 CITROËN 專用的球接頭 (FRONT LOWER LH/ RH)。本產品為 OEM 規格替代零件，適配原廠料號 16 072 984 80,16 072 985 80,3640.56,3640.59,3640.62,3640.66。

PARAMETER	METRIC / VALUE
Designation	Ball Joint
Position	FRONT LOWER LH/ RH
OE 替代料號 (Original Equipment Numbers)	16 072 984 80 16 072 985 80 3640.56 3640.59 3640.62 3640.66
Length	0 mm
Width	0 mm
Height	0 mm
Net Weight	0.5 kg

輸入廠牌、車款、車型年份或 17 位 VIN 碼，系統將自動比對原廠規格，為您精確鎖定愛車專用的適配零件。

CTE No.	POSITION	OE No.
CBJ15008A	FRONT LOWER LH/ RH	3 52 067 352087 3640.77 93188808 93190907 98 093 384 80
CBJ25001A	FRONT LOWER LH/ RH	16 072 984 80 16 072 985 80 3640.56 3640.59 3640.62 3640.66
CS-2512L	FRONT LOWER LH	3520.W7 3520.W8 3520.X1 3520.Y1 98 032 865 80 98 136 127 80
CS-2512R	FRONT LOWER RH	3521.S9 3521.T0 3521.T3 3521.V2 98 032 864 80 98 136 125 80
CS47012L	FRONT LOWER LH	1014013005
CS47012R	FRONT LOWER RH	1014013007
CSL16011	FRONT (A= 335MM)	16 073 234 80 16 466 219 80 5087.45 5087.59 5087.66 5087.71 5087.74 96288787 98 000 861 80 98 088 682 80 E459713

Model (Year)
C3 I (FC_, FN_) C3 II (SC_) C3 PICASSO (SH_) C3 Pluriel (HB_)
