Rubber Bushing

PORSCHE / PANAMERA (970) / Rubber Bushing / FRONT LOWER ARM REAR / CBH34013

Technical Specification Matrix

CBH34013 是 PORSCHE 專用的橡膠襯套 (FRONT LOWER ARM REAR)。本產品為 OEM 規格替代零件，適配原廠料號。

PARAMETER	METRIC / VALUE
Designation	Rubber Bushing
Position	FRONT LOWER ARM REAR
OE 替代料號 (Original Equipment Numbers)
Length	86 mm
Width	80 mm
Height	87 mm
Net Weight	0.5 kg

輸入廠牌、車款、車型年份或 17 位 VIN 碼，系統將自動比對原廠規格，為您精確鎖定愛車專用的適配零件。

CTE No.	POSITION	OE No.
CBH19040	FRONT LOWER LH/RH	4G0 407 183 4G0 407 183A 4G0 407 183B 4H0 407 183 4H0 407 183B 4H0 407 183C 970 341 245 21
CBH20010	FRONT UPPER ARM INNER	7L0 407 077
CBH34010	FRONT LOWER ARM REAR	970 341 245 01 970 341 245 02 970 341 245 10
CBH34011	FRONT LOWER ARM OUTER	970 341 243 01
CBH34012	FRONT LOWER ARM INNER	970 331 041 02 970 331 042 02 970 341 241 00 970 341 241 01
CBH34013	FRONT LOWER ARM REAR
CBH34014	FRONT LOWER ARM INNER	970 341 053 23 970 341 053 24 970 341 054 23 970 341 054 24
CBH34015	FRONT LOWER ARM REAR	970 341 245 01 970 341 245 02 970 341 245 10
CBH34025	REAR UPPER ARM	970 331 043 00 970 331 047 00
COS34005	FRONT	970 341 051 03 970 341 051 10 970 341 053 04 970 341 054 04
CS-3408L	FRONT LOWER LH	970 341 053 03 970 341 053 04
CS-3408R	FRONT LOWER RH	970 341 054 03 970 341 054 04
CS-3409	FRONT UPPER LH/RH	970 341 051 03 970 341 051 10 970 341 151 01
CS-3417L	FRONT LOWER LH	970 341 053 23 970 341 053 24
CS-3417R	FRONT LOWER RH	970 341 054 23 970 341 054 24
CS-3439L	FRONT LOWER LH	970 341 053 03 970 341 053 04
CS-3439R	FRONT LOWER RH	970 341 054 03 970 341 054 04
CS-3452	REAR UPPER LH/ RH	970 331 043 00
CS-3453	REAR UPPER LH/ RH	970 331 047 00
CS-3455	FRONT UPPER LH/ RH	970 341 051 22 970 341 051 23
CSL34005	REAR AXLE LH/RH	970 333 069 03 970 333 069 05 971 511 467B 971 511 467D 971 511 467F
CSL34006	REAR AXLE LH/RH	970 343 069 01 970 343 069 02 970 343 069 03
CSL34007	FRONT AXLE LH/RH	970 343 069 21 970 343 069 22 970 343 069 23
