Technical Specification Matrix
CBH21066 是 MERCEDES-BENZ 專用的 橡膠襯套 (FRONT UPPER ARM INNER)。
本產品為 OEM 規格替代零件，適配原廠料號 166 330 17 07,166 330 18 07,166 331 02 14,166 333 00 00,166 333 07 14,251 330 07 07,251 330 08 07,251 330 25 00,251 330 26 00,251 333 01 14,A166 330 17 07,A166 330 18 07,A166 331 02 14,A166 333 00 00,A166 333 07 14,A251 330 07 07,A251 330 08 07,A251 330 2。
| PARAMETER | METRIC / VALUE |
|---|---|
| Designation | Rubber Bushing |
| Position | FRONT UPPER ARM INNER |
| OE 替代料號 (Original Equipment Numbers) |
|
| Length | 56 mm |
| Width | 56 mm |
| Height | 45 mm |
| Net Weight | 0.2 kg |
Find More Auto Parts
快速找到適配您需要的專業零件
輸入廠牌、車款、車型年份或 17 位 VIN 碼，系統將自動比對原廠規格，為您精確鎖定愛車專用的適配零件。
Compatible Models
| CTE No. | DESIGNATION | POSITION | OE No. | |
|---|---|---|---|---|
 |
CBH21046L | FRONT LOWER ARM LH REAR |
|
|
 |
CBH21046R | FRONT LOWER ARM RH REAR |
|
|
 |
CBH21047 | FRONT LOWER ARM INNER |
|
|
 |
CBH21048 | FRONT LOWER ARM OUTER |
|
|
 |
CBH21066 | FRONT UPPER ARM INNER |
|
|
 |
CBJ21011 | FRONT AXLE LH/ RH |
|
|
 |
CRE21013 | FRONT AXLE LH/ RH |
|
|
 |
CS-2145L | FRONT UPPER LH |
|
|
 |
CS-2145R | FRONT UPPER RH |
|
|
 |
CS-2163L | FRONT LOWER LH |
|
|
 |
CS-2163R | FRONT LOWER RH |
|
|
 |
CSL21048L | FRONT AXLE LH |
|
|
 |
CSL21048R | FRONT AXLE RH |
|
| Model (Year) |
|---|
|
GL-CLASS (X164) GL-CLASS (X166) GLE (W166) GLE Coupe (C292) GLS (X166) M-CLASS (W164) M-CLASS (W166) R-CLASS (W251, V251) |
