Rubber Bushing

MAZDA / CX-5 (KE, GH) / Rubber Bushing / FRONT LOWER ARM REAR / CBH03089

Name: CBH03089
Brand: CTE
SKU: CBH03089
Price: 441.00 TWD
Availability: InStock

Technical Specification Matrix

CBH03089 是 MAZDA 專用的橡膠襯套 (FRONT LOWER ARM REAR)。本產品為 OEM 規格替代零件，適配原廠料號 B45A 34 460,B60P 34 300,B60P 34 300 G,B60P 34 350,B60P 34 350 G,B60S 34 300,B60S 34 300 G,B60S 34 350,B60S 34 350 G,KD35 34 300 D,KD35 34 300 E,KD35 34 300 F,KD35 34 300 G,KD35 34 300 H,KD35 34 350 D,KD35 34 350 E,KD35 34 350 F,KD35 34 350 G,KD35 34 350 H。

更多相關商品

PARAMETER	METRIC / VALUE
Designation	Rubber Bushing
Position	FRONT LOWER ARM REAR
OE 替代料號 (Original Equipment Numbers)	B45A 34 460 B60P 34 300 B60P 34 300 G B60P 34 350 B60P 34 350 G B60S 34 300 B60S 34 300 G B60S 34 350 B60S 34 350 G KD35 34 300 D KD35 34 300 E KD35 34 300 F KD35 34 300 G KD35 34 300 H KD35 34 350 D KD35 34 350 E KD35 34 350 F KD35 34 350 G KD35 34 350 H
Length	81 mm
Width	81 mm
Height	58 mm
Net Weight	0.3 kg

Find More Auto Parts

快速找到適配您需要的專業零件

輸入廠牌、車款、車型年份或 17 位 VIN 碼，系統將自動比對原廠規格，為您精確鎖定愛車專用的適配零件。

Compatible Models

CTE No.	POSITION	OE No.
CBH03084L	FRONT LOWER ARM LH REAR	B45A 34 460 B45A-34-350 B45A-34-350D B45A-34-350E B45G-34-350E B60P 34 350 B60P 34 350 G B60P-34-350 B60P-34-350B B60P-34-350C B60P-34-350D B60P-34-350E B60P-34-350F B60P-34-350G B60S 34 350 B60S 34 350 G B60S-34-350 B60S-34-350B B60S-34-350D B60S-34-350E
CBH03084R	FRONT LOWER ARM RH REAR	B45A 34 460 B45A-34-300 B45A-34-300A B45A-34-300C B45A-34-300D B45A-34-300E B45G-34-300 B45G-34-300A B45G-34-300C B45G-34-300E B60P 34 300 B60P 34 300 G B60P-34-300 B60P-34-300B B60P-34-300D B60P-34-300E B60P-34-300F B60P-34-300G B60S 34 300 B60S 34 300 G
CBH03085	FRONT LOWER ARM INNER	B45A-34-300 B45A-34-300A B45A-34-300C B45A-34-300D B45A-34-300E B45A-34-350 B45A-34-350D B45A-34-350E B45G-34-300 B45G-34-300A B45G-34-300C B45G-34-300E B45G-34-350E B60P-34-300 B60P-34-300B B60P-34-300D B60P-34-300E B60P-34-300F B60P-34-300G B60P-34-350
CBH03089	FRONT LOWER ARM REAR	B45A 34 460 B60P 34 300 B60P 34 300 G B60P 34 350 B60P 34 350 G B60S 34 300 B60S 34 300 G B60S 34 350 B60S 34 350 G KD35 34 300 D KD35 34 300 E KD35 34 300 F KD35 34 300 G KD35 34 300 H KD35 34 350 D KD35 34 350 E KD35 34 350 F KD35 34 350 G KD35 34 350 H
CBH03104	FRONT LOWER ARM REAR	D09H-34-300C D09H-34-350C D10E-34-300 D10E-34-300B D10E-34-350 D10E-34-350B D10E-35-460 DA7H-34-300B DA7H-34-350B
CBH03105	FRONT LOWER ARM INNER	D09H-34-300C D09H-34-350C D10E-34-300 D10E-34-350 D10E-34-470 DA7H-34-300B DA7H-34-350B
CBJ03024		B45A-34-300 B45A-34-300A B45A-34-300C B45A-34-300D B45A-34-300E B45A-34-350 B45A-34-350D B45A-34-350E B45G-34-300 B45G-34-300A B45G-34-300C B45G-34-300E B45G-34-350E B60P-34-300 B60P-34-300B B60P-34-300D B60P-34-300E B60P-34-300F B60P-34-300G B60P-34-350
CRE02133	FRONT AXLE LH/ RH	45503-09100 45503-0B020 45503-29395 45503-29665 45503-49015 45503-49035
CRE02152	FRONT AXLE LH/ RH	45503-29665 45503-39165
CRE03061	FRONT AXLE LH/ RH	KD31-32-240 KD31-32-240A
CS-372L	FRONT LOWER LH	KA0G-34-350B KA0G-34-350F KA0G-34-350G KA1G-34-350 KA1G-34-350B KA1G-34-350F KA1G-34-350G KD35-34-350D KD35-34-350F KD35-34-350G KD35-34-350H KD35-34-350J KD35-34-350P KD53-34-350A KD53-34-350B KD53-34-350C KD53-34-350D KD53-34-350E
CS-372R	FRONT LOWER RH	KA0G-34-300B KA0G-34-300F KA0G-34-300G KA1G-34-300 KA1G-34-300B KA1G-34-300F KA1G-34-300G KD35-34-300D KD35-34-300F KD35-34-300G KD35-34-300H KD35-34-300J KD35-34-300P KD53-34-300A KD53-34-300B KD53-34-300D KD53-34-300E KD53-34-300F
CS-396L	FRONT LOWER LH	D10E-34-350 D10E-34-350A D10E-34-350B D24H-34-350 D24H-34-350A D24H-34-350B
CS-396R	FRONT LOWER RH	D10E-34-300 D10E-34-300A D10E-34-300B D24H-34-300 D24H-34-300A D24H-34-300B
CS03118	REAR AXLE LH/ RH	KB7W-28-C10 KD3528C10
CSL03076	FRONT AXLE LH/ RH	K750507 KD35-34-170 MR589437
