Rubber Bushing

HONDA / CITY V Saloon (GM2, GM3) / Rubber Bushing / FRONT LOWER ARM RH REAR / CBH01046R

Technical Specification Matrix

CBH01046R 是 HONDA 專用的橡膠襯套 (FRONT LOWER ARM RH REAR)。本產品為 OEM 規格替代零件，適配原廠料號 51350-TF0-030,51350-TG0-T02,51350-TG5-C01,51350-TH9-000。

PARAMETER	METRIC / VALUE
Designation	Rubber Bushing
Position	FRONT LOWER ARM RH REAR
OE 替代料號 (Original Equipment Numbers)	51350-TF0-030 51350-TG0-T02 51350-TG5-C01 51350-TH9-000
Length	167 mm
Width	207 mm
Height	89 mm
Net Weight	1.5 kg

輸入廠牌、車款、車型年份或 17 位 VIN 碼，系統將自動比對原廠規格，為您精確鎖定愛車專用的適配零件。

CTE No.	POSITION	OE No.
CBH01046L	FRONT LOWER ARM LH REAR	51360-TF0-020 51360-TF0-030 51360-TG0-T02 51360-TH9-000
CBH01046R	FRONT LOWER ARM RH REAR	51350-TF0-030 51350-TG0-T02 51350-TG5-C01 51350-TH9-000
CBH01047	FRONT LOWER ARM INNER	40170-20500 40170-20700 40170-31400 40170-31500 40170-32700 40170-32800 51350-SYY-010 51350-T5A-J00 51350-T5A-J01 51350-T5A-J02 51350-T5A-J11 51350-T5R-A01 51350-T7A-003 51350-T7A-901 51350-T7J-H01 51350-T7W-A00 51350-T7W-A50 51350-T8M-G00 51350-TF0-030 5
CS-154L	FRONT LOWER LH	51360-SYY-010 51360-TF0-020 51360-TF0-030 51360-TG0-T02 51360-TG5-C01 51360-TH9-000 51360-TK6-A01
CS-154R	FRONT LOWER RH	51350-SYY-010 51350-TF0-020 51350-TF0-030 51350-TG0-T02 51350-TG5-C01 51350-TH9-000 51350-TK6-A01

Model (Year)
CITY V Saloon (GM2, GM3) FREED I (GB3, GB4, GP3) FREED SPIKE (GB3, GB4, GP3) INSIGHT (ZE_) JAZZ III (GE_, GG_, GP_, ZA_) \| FIT JAZZ IV (GK_) \| FIT
